1. Carefully place the Power Supplies in the slots in the Rack.
2. Make sure that the connector at the back seats properly. Insert a
flat blade in the slots at the top and bottom of the power supply
cover while pulling backward to open the cover.
3. Fasten the screws (located in the face of the power supply) into
the tabs at the top and bottom of the rack. Set the Torque to 0.4 -
0.5 N.m (3.5 - 4.4 Lb-In). See the following figure for power supply
mounting details.
70
