Specifications - General Specifications
Revision 19 HC900 Process Controller Installation and User Guide 195
06/14
C30 C50 C70 C75
12 I/O slot chassis with
redundant power
support
5.4”(137mm) H x 26.9”(683.3mm) W x 6.0”
*
(151.7mm) D (rear mounting plate extends height
to 6.9” (175.3mm)
Redundant CPU rack
N/A
* 6.4 (162.6) for 32 DI/DO and 16 AI Modules
5.4”(137mm) H x
10.3”(261.6mm) W x
6.0,,”
*
(151.7mm) D
(rear mounting plate
extends height to 6.9”
(175.3mm)
I/O Wiring
Type
Removable terminal blocks
Terminal Block Styles
20 screw: Barrier or Euro-style, tin-plated or gold-plated (for DC connections)
36 screw: Euro style gold plated (Required with certain higher capacity modules)
Gauge wires
20 screw:
Barrier style – #14 to 26 AWG, solid or stranded
Euro-style - #14 to 26 AWG, solid or stranded
36-screw:
Euro-style - #12 to 26 AWG, solid or stranded
Shield terminals
Optional brackets mounted top/bottom of rack
Power (P01)
Voltage
Universal power, 90 to 264VAC, 47 to 63 Hz
In Rush Current
7 Amps peak-to-peak for 150 ms at 240VAC
Input rating
130 VA
Output rating
60W
Fuse
Internal non-replaceable fuse. User installed external fuse.
Power (P02)
Voltage
Universal power, 90 to 264VAC, 47 to 63 Hz
In Rush Current
7 Amps peak-to-peak for 120 ms at 240VAC
Input rating
90 VA
Output rating
28W
Fuse
Internal non-replaceable fuse. User installed external fuse.
Power (P24)
Voltage
21 to 29VDC
In Rush Current
30A for 3ms @29VDC
Input rating
72.5W
Output rating
60W
Fuse
Internal non-replaceable fuse. User installed external fuse.
Normal Scan Time
500ms. Each analog input card has its own A/D converter providing parallel processing.
Fast Scan Time 53ms for up to~250 fast
logic blocks
67ms for up to ~315
fast logic blocks
107ms for up to ~400
fast logic blocks
27ms for up to ~250 fast
logic blocks
53ms for up to~500 fast
logic blocks
67ms for up to ~780 fast
logic blocks
107ms for up to ~1040
fast logic blocks
133ms for up to ~1300
fast logic blocks
27ms for up to ~330 fast
logic blocks
53ms for up to~660 fast
logic blocks
67ms for up to ~1040
fast logic blocks
107ms for up to ~1380
fast logic blocks
133ms for up to ~1700
fast logic blocks
267ms for up to~3300
fast logic blocks
53ms for up to~500 fast
logic blocks
67ms for up to ~780 fast
logic blocks
107ms for up to ~1040
fast logic blocks
133ms for up to ~1300
fast logic blocks
267ms for up to~2500
fast logic blocks
Detection+Failover
Time from Lead to
Reserve CPU
N/A
Up to 4 analog scan
cycles
Run-Mode Edit
Transfer Time
3 normal scan times (1.5 sec. typical) for all configuration edits not including I/O changes
Operating Modes
Run (No configuration download in this position)
Run/Program (Download allowed)
Program (Outputs Off, initialization on download).
Offline mode is available via software selection (for AI calibration).
