I/O Module Installation and Wiring - I/O Module Installation Procedures
80 HC900 Process Controller Installation and User Guide Revision 19
06/14
Step Procedure Comments Reference
9
Connect wire-tie into the
top and/or bottom of the
Rack.
Form a bend in each wire
to provide strain relief, and
secure the wire bundle
with the tie.
10
Install I/O modules in
racks. Be sure to follow
placement guidelines
under Heat Rise De-rating
page 43.
