AN On/Off
Int
Programming Codes
SCPI:
AM:SOURce
EXTernal
AM:STATe ON/OFF
Analyzer: AM1 function on, AM0 function off
See
Also
(MOD), also see “AM” and “Modulation”.
AM
On/Off
Int
Function Group
Menu Map
Description
Programming Codes
See Also
(MOD_)
4
This
softkey
(Option 002 only) activates the internal amplitude
modulation mode. No external source is needed.
When internal AM is in effect, the parameters are controlled by
the following soft keys:
Internal AM Rate Internal AM Depth
AM Type
100%/V
AM Type
IOdB/V
Deep AM Waveform Menu.
An asterisk next to the key label indicates that internal AM is active
and
HP~
is displayed on the message line. Both amplitude and pulse
modulation can be in effect simultaneously.
SCPI:
AM:SOURce
INTernal
AM:STATe ON/OFF
Analyzer: NONE
a],
also see “AM” and “Modulation”.
Operating and Programming Reference
A- 17
