I
Internal
AM
Depth
Function Group
Menu Map
Description
Programming Codes
See Also
(MOD)
4
This
softkey
(Option 002 only) lets you set the AM depth for
internally-generated AM. Use the numeric entry keys, arrow
keys, or rotary knob to change the value of the depth. The swept
signal generator accepts values from 0 to 99.9 percent (0 percent is
equivalent to no modulation) and has a resolution of 0.1 percent.
The factory preset depth is 30 percent.
SCPI:
AM[:DEPTH] <
num>[PCT]]MAXimum]MINinum]<num>DB
UNIT:AM
DB]PCT
Analyzer: NONE
(MOD), also see “AM” and “Modulation”.
Operating and Programming Reference I-1
