FM
On/Off
DC
FM
On/Off
AC
Function Group
MODULATION
Menu Map
4
Description
This
softkey
lets you select AC coupled frequency modulation
(FM), and makes FM deviation frequency the active function.
FM sensitivity is selectable. Use the rotary knob, up/down, or
numeric entry keys to choose, 100 kHz, 1.00 MHz/V or 10.0 MHz/V.
Frequency deviation is dependent on the magnitude of the input
signal. An asterisk next to the key label indicates that this feature is
active.
Programming Codes
SCPI:
FM:SENSitivity
<num>[freq/V
suffix]]MAXimum]MINimum
FM:COUPling AC
FM:STATe ON]OFF]l]O
Analyzer:
FM1 function on, followed by either 100 kHz,
lMHz,
or 10 MHz
FM0 function off
See Also
m),
CONNECTORS
FM
On/Off
DC
Function Group
MODULATION
Menu Map
4
Description
This
softkey
lets you select DC coupled frequency modulation
(FM) and makes FM deviation frequency the active function.
FM sensitivity is selectable. Use the rotary knob, up/down, or
numeric entry keys to choose, 100 kHz, 1.00 MHz/V or 10.0 MHz/V.
Frequency deviation is dependent on the magnitude of the input
signal. When DC FM is chosen the swept signal generator displays
DC FM on the message line. An asterisk next to the key label indicates
that this feature is active.
Operating and Programming Reference F-13
