Up/Down
Power
Function Group
POWER
Menu Map
5
Description
This softkey activates the power step size function. It can be set
from 0.01 to 20 dB. In this mode, power is stepped by the up/down
arrow keys. An asterisk next to the key label indicates this feature is
active.
Programming Codes
SCPI:
POWer:STEP[:INCrement]
<num>[DB]
or
MAXimum]
MINimum
POWer:STEP:AUTO ON]OFF]l]O
Analyzer: SP or SHPL and UP or DOWN
See Also
Up/Dn
Size CW,
Up/Dn
Size Swept
“Programming Typical Measurements” in Chapter 1
Up/Dn
Size
CW
Function Group
FREQUENCY
Menu Map
2
Description
This softkey lets you set the frequency step size for the CW
frequency mode. The step size may be set from 1 Hz to
10 GHz. The factory preset size is 100 MHz. CW frequency is
incremented/decremented by pressing the up/down arrow keys.
If an underline cursor appears under a digit in the entry display, then
the value will be modified by the up/down arrow keys or the rotary
knob. The increment/decrement size in this case is the underlined
digit by the power of 10.
If the up/down function is on (asterisk next to key label) and the
cursor is not under one of the active entry area digits, then frequency
value is changed by the up/d
own size using either the up/down arrow
keys or the rotary knob.
U-2 Operating and Programming Reference
