Rack Flange Kit for
Option 913 swept signal generators are supplied with rack flanges
Swept Signal
and the necessary hardware to install them on the swept signal
Generators with
generator without removing the instrument handles. The following
Handles Attached
table itemizes the parts in this kit.
(Option 913)
Table 3-6.
Rack Flange Kit for Swept Signal Generators with
Handles Attached Contents
1
Quantity
1
Description
I
2
I
I
Rack Mount Flanges
8
Screws
CAUTION
Ventilation Requirements: When installing the instrument in a
cabinet, the convection into and out of the instrument must not be
restricted. The ambient temperature (outside the cabinet) must be
less than the maximum operating temperature of the instrument
by 4
“C
for every 100 watts dissipated in the cabinet. If the total
power dissipated in the cabinet is greater than 800 watts, then forced
convection must be used.
Installation 3-15
