Peak
RF
Once
Function Group
POWER, USER CAL
Menu Map
5,9
Description
This softkey appears in two locations: the POWER Tracking Menu
and the USER CAL Tracking Menu. The operation is the same in
both locations.
This softkey causes an instantaneous, one-time execution of the
peaking function when the swept signal generator is in the CW or
manual sweep mode. It aligns the output filter (SYTM) so that its
passband
is centered on the RF output.
Programming Codes
SCPI: CALibration:PEAKing[:EXECute]
Analyzer: SHAK
See Also
Auto Tracking,
Peak RF Always, Tracking Menu
“Optimizing Swept Signal Generator Performance” in Chapter I
Function Group
POWER
Menu Map
NONE
Description
This
hardkey
lets you control the output power level of the swept
signal generator. The swept signal generator has different power
leveling modes and leveling points, and as such, the [POWER LEVEL)
key controls different aspects of the power level (ALC) system.
The following is an explanation of power level operation in the
different ALC system configurations.
In Normal, Internal, the (POWER LEVEL) key controls the output
power level of the swept signal generator directly. The attenuator
(if present) is controlled together with the complete range of the ALC
system
(t25
to -20
dBm).
P-2 Operating and Programming Reference
