AM Cal Menu
Function Group
USER CAL
Menu Map 9
Description
This softkey accesses the AM bandwidth calibration menu.
AM BW Cal Always Causes an AM bandwidth calibration
to be performed every time a
frequency or power parameter is
changed.
AM BW Cal Once
Causes a single AM bandwidth
calibration to be performed.
See Also
Softkeys listed above.
AM Menu
Function Group IlvloD)
Menu Map 4
Description
This softkey (Option 002 only) accesses the amplitude modulation
softkeys. These softkeys engage external and internal amplitude
modulation. They allow you to define the scaling, waveform, rate,
and depth of the internal AM.
AM On/Off Ext
Toggles on and off the amplitude modulation mode
for an external AM source.
AM On/Off Int
Toggles on and off the amplitude modulation mode
using the internal AM generator.
Internal AM Rate
Sets the rate of the internal amplitude modulation.
Internal AM Depth
Sets the depth of the internal amplitude
modulation.
AM Type 100%/V Sets the scale to linear at 100% per volt.
AM Type IadBfv Sets the scale to exponential at 10 dB per volt.
Deep AM
Opens the ALC loop when the detected signal
level power is below the detector’s sensing range.
A-14 Operating and Programming Reference
