Pulse Sync Out (Option 002 only)
Outputs a 50 ns wide TTL pulse synchronized to the leading edge of
the internally-generated pulse. (BNC female, rear panel.)
AM/FM Output (Option 002 only)
Outputs the internally-generated AM or FM waveform. This output
can drive 50 ohms or greater. The AM output is scaled the same as
it is generated, either
100%/V
or 10
dB/V.
The FM scaling depends
on the FM deviation selected. (BNC female, rear panel.)
Models
HP 83620B: 10 MHz to 20 GHz
HP
83622B:
2 to 20 GHz
HP 83623B: 10 MHz to 20 GHz High Power
HP 83624B: 2 to 20 GHz High Power
HP 83630B:
10 MHz to 26.5 GHz
HP 83640B:
10 MHz to 40 GHz
HP 83650B:
10 MHz to 50 GHz
Options
Option 001 Add Step Attenuator
With this option, minimum
settable
output power is -110
dBm.
Maximum leveled output power is lowered by 1.5 dB to 20 GHz, and
2 dB above 20 GHz, and 2.5 dB above 40 GHz.
Option 002 Add Internal Modulation Generator
Adds a digitally-synthesized internal modulation waveform
source-on-a-card to the HP 8360. It provides signals that would
otherwise be supplied to the external modulation inputs.
Option 004 Rear Panel RF Output
Moves the RF Output, External ALC Input, Pulse Input/Output,
AM Input, and FM Input connectors to the rear panel.
Option 006 Fast Pulse Modulation
Improves pulse rise/fall time to 10 ns. Also effects maximum leveled
output power and harmonic performance.
Option 008 1 Hz Frequency Resolution
Provides frequency resolution of 1 Hz.
Option 700 MATE System Compatibility
Provides CIIL programming commands for MATE system
compatibility.
Specifications
2c-
17
