Internal
AM
Rate
Function Group
Menu Map
Description
Programming Codes
See Also
(MOD)
4
This softkey (Option 002 only) lets you set the AM rate for
internally-generated AM. Use the numeric entry keys, arrow keys, or
rotary knob to change the rate. The swept signal generator accepts
values from 1 Hz to 1 MHz, however it is specified to 1 MHz only for
a sine waveform. Refer to the specifications. The factory preset rate
is 100 kHz.
SCPI: AM:INTernal:FREQuency <num>[<freq suffix>]
IMAXimumJMINimum
Analyzer: NONE
IIvIoD_),
also see “AM” and “Modulation”.
Internal
AM
Waveform
Noise
Function Group
Menu Map
Description
Programming Codes
See Also
(MOD]
4
This softkey (Option 002 only) lets you set the AM waveform to
noise (white noise AM rate;
gaussian
distribution centered around
AM depth) for internally-generated AM. An asterisk next to the key
label indicates that this feature is active. The factory preset default
is sine wave.
SCPI: AM:INTernal:FUNCtion NOISe
Analyzer: NONE
(MOD_),
also see “AM” and “Modulation”.
l-2 Operating and Programming Reference
