Internal
Pulse
Mode
Trigger
Function Group
IhnoD)
Menu Map
4
Description
This softkey (Option 002 only) lets you set the internal pulse
generator to trigger on the leading edge of the externally generated
pulse.
Programming Codes
SCPI: PULM:INTernal:TRIGger:SOURce
EXTernal
Analyzer: NONE
See Also
(MOD), also see “Pulse” and “Modulation”.
Invert
Input
Function Group (MOD)
Menu Map
4
Description
This softkey (Option 002 only) inverts the logic of the external pulse
input.
With this function active,
+5
V turns off RF power.
Programming Codes
SCPI: PULM:EXTernal:POLarity
INVerted
Analyzer: NONE
See Also
II,
1
MOD a so see “Pulse” and “Modulation”.
l-12 Operating and Programming Reference
