Internal
Pulse Generator Period
Internal Pulse Mode Gate
Turns on the internal pulse mode during the
positive cycle of the externally generated pulse.
Internal Pulse Mode Trigger
Triggers on the leading edge of the external pulse
input.
Programming Codes
SCPI: NONE, see the individual softkeys listed.
Analyzer: NONE
See Also
0,
1
MOD
a so see “Modulation” and “Pulse”.
Internal
Pulse
Generator
Period
Function Group
INIOD)
Menu Map
4
Description
This
softkey
(Option 002 only) lets you set a value for the internal
pulse generator’s pulse period. The pulse is adjustable from
300 ns to 400 ms with 25 ns resolution. The factory preset default
is 2 ms pulse period. When this feature is active, its current value is
displayed in the active entry area.
Since period and rate are inversely related, if both are given values,
only the last one will be applied which will cause the first one to be
recalculated. Use the one that is convenient for your application. For
example, if you set the pulse period, do not change the pulse rate
(the swept signal generator automatically adjusts the rate to match
the period).
Programming Codes
SCPI: PULS:INTernal:PERiod <num>[time suffix]]MAXimum]MINimum
Analyzer: NONE
See Also
0,
1
MOD
a so see “Pulse” and “Modulation”.
Operating and Programming Reference l-9
