Saving and
Recalling an
Instrument State
The save/recall registers store and access a previously set instrument
state.
For example, set the swept signal generator to sweep from 3
GHz
to
15 GHz at a -10 dB power level, with markers 1 and 2 set at 4.5 and
11.2 GHz.
Press
ISTART)
(?J
(GHz).
Press
LSTOP)
(iJ
Q
(GHz).
Press
(POWER
LEvEL)
I-)
(iJ
@
(dB(m)).
Press (MARKER).
Select Marker Ml
@o
@
(GHz).
Select Marker M2
0
0
0
@
LGHz).
To save this instrument state in register 1, press (SAVE)
0.
To verify
that the swept signal generator has saved this state:
Press
(PRESET).
Press (RECALL)
(iJ.
Press
(NIARKER).
The active entry area displays:
-->
RECALL REGISTER: 1 RECALLED
Notice the sweep end points, power level, and the asterisks next to
the marker 1 and 2 key labels.
You can save instrument states in registers 1 through 8. Register
0 saves the last instrument state before power is turned off. When
power is turned on, register 0 is automatically recalled.
I-16
Getting Started Basic
