Uncoupl
Atten
Function Group
Menu Map
Description
Programming Codes
See Also
POWER
This softkey uncouples the attenuator (if there is one) from the ALC
system. It allows independent control of attenuator settings. An
asterisk next to the key label indicates that this feature is active.
To set the attenuator after it is uncoupled, select Set
Atten.
To
view the current ALC and attenuator settings, press POWER LEVEL .
SCPI: POWer:ATTentuation:AUTO ON]OFF]l]O
Analyzer: SHPS <num>
[DBIDM]
to set the ALC, SHSL <num>
[DBIDM]
to attenuator. PL causes the attenuator couple to the ALC.
(ALC),
(POWER LEVEL), Set
Atten
“Working with Mixers/Reverse Power Effects” in Chapter 1
Unlock
Info
Function Group
Menu Map
Description
Programming Codes
See Also
SERVICE
6
This
softkey
causes the swept signal generator to display
lock/unlocked status of all the phase-lock-loops. An asterisk next to
the key label indicates this feature is active.
SCPI: DIAGnostics:OUTput:UNLocks?
Analyzer: SHT3 or SHM4 diagnostics test results.
STATUS MESSAGES
Chapter 4, “OPERATOR’S CHECK and ROUTINE
MAINTENANCE”
Operating and Programming Reference U-l
