Marker
Ml
Function Group
MARKER
Menu Map
3
Description
The softkeys labeled Marker Ml through Marker M5 function
identically. The softkey turns the marker off/on. When an asterisk
appears next to the key label, it indicates that the marker is on, but
not necessarily active. A marker is only active when it is indicated in
the active entry area.
The active entry area displays the active marker and its frequency
value. Use the rotary knob, the ARROW keys, or the entry keys to
set the frequency. Markers are displayed normally as Z-axis intensity
dots, but can be changed to amplitude pulses (Amp1 Markers
).
When a marker is turned off, the frequency value of that marker
is retained in memory. If the marker is reactivated, the stored
frequency value is recalled for that marker.
The frequency value of Ml and of M2 can also be used to define
parameters in two other marker features:
Ml--M2
Sweep and
Start=Mi
Stop=M2.
Programming Codes
SCPI:
MARKer[l][:FREQuency] <num>[freq suffix] or
MAXimumIMINimum
MARKer[l]:STATe ON]OFF]l]O
Analyzer:
Ml function on, MO function off.
See Also
Amp1
Markers,
MI--M2
Sweep,[%%?$,
MkrRef
Menu,
Start=Mi
Stop=M2
“Marker Operation” in Chapter 1
“Programming Typical Measurements” in Chapter 1
M-4 Operating and Programming Reference
