Pulse Menu
Function Group IIV1OD)
Menu Map 4
Description
This description is for the Pulse Menu softkey for swept signal
generators with Option 002. For the standard 002 Pulse Menu
softkey go to the “Pulse Menu”
heading that precedes this one.
This softkey accesses the pulse modulation softkeys. These softkeys
engage external, internal, and scalar pulse modulation. They allow
you to define the rise time, and give access to the internal menu for
defining the parameters of the internally-generated pulse modulation.
Pulse On/Off Ext
Pulse On/Off Scalar
Pulse On/Off Int
Internal Menu
Pulse Rise Time East
Pulse Rise Time Slow
Pulse Rise Time Auto
Invert Input
Toggles on and off the pulse modulation
mode for an external pulse source.
Toggles on and off the internal scalar
modulation mode.
Toggles on and off the internal pulse
modulation mode.
Gives access to the internal menu
for defining the parameters of the
internally-generated pulse modulation.
Applies a fast rise pulse filter to both
internal and external pulse waveforms.
Applies a slow rise pulse filter to both
internal and external pulse waveforms.
Automatically applies the appropriate
filter (fast or slow) to both internal and
external pulse waveforms.
Inverts the pulse input logic. When
active, a +5 V input turns RF power off.
Programming Codes
SCPI: NONE, see the individual softkeys listed.
Analyzer: NONE
See Also 0, 1
MOD
a so see “Modulation” and “Pulse”.
P-18 Operating and Programming Reference
