Pulse OnlQffIntrnl.
Pulse
On/Off
Extrnl
Function Group (MOD)
Menu Map
4
Description
This softkey activates the pulse modulation mode for an external
pulse source. The pulse source is connected to the PULSE INPUT
BNC connector and fed to the pulse modulator through a buffer
circuit.
When pulse modulation is in effect, the RF output is turned on
(programmed power is produced) and off
(>80
dB attenuation) at a
rate determined by the pulse modulation input. Pulse and amplitude
modulation can be in effect simultaneously. An asterisk next to the
key label indicates that this feature is active.
Programming Codes
SCPI:
PULSe:SOURce
EXTernal
PULSe[:STATe] ON]OFF]l]O
Analyzer: PM1 function on, PM0 function off.
See Also
IALCJ,
CONNECTORS,
Ir\noD),
Pulse Menu
Pulse
On/Off
Intrnl
Function Group
m
Menu Map
4
Description
This softkey activates pulse modulation mode using the internal pulse
generator. No external connection is needed. When internal pulse
modulation is selected, the PULSE INPUT BNC becomes an output
for the internally generated signal. An asterisk next to the softkey
label indicates that this feature is active. The pulse parameters
(width, period, rate, rise time, etc.) are controlled by softkeys. See
Pulse
Menu (or Internal Menu for swept signal generators
with
Option 002) for a list of these softkeys.
Operating and Programming Reference P-19
