Pulse
OnlQffIntrnl
Programming Codes
SCPI:
PULSe:SOURce
INTernal
PULSe[:STATe] ON]OFF]l]O
Analyzer: NONE
See
Also
(x),
(MOD),
Pulse Menu
Pulse
On/Off
Scalar
Function Group
Menu Map
Description
Programming Codes
(MOD)
4
This
softkey
activates pulse modulation mode, and sets the internal
pulse generator to produce 27.778 kHz square wave pulses
(18 ps pulse width, 36 ps pulse period). The rise and fall times of
the RF envelope are approximately 2 ps. These pulses allow proper
operation with HP scalar network analyzers in ac detection mode.
An asterisk next to the key label indicates that this feature is active.
SCPI:
PULSe:SOURce SCALar
PULSe[:STATe] ON]OFF]l]O
Analyzer: SHPM function on, PM0 function off.
See Also
Fp,F,
Pulse Menu
a
P-20 Operating and Programming Reference
