Step
Swp
Pt
Trig
Ext
Function Group
FREQUENCY
Menu Map
2
Description
When this
softkey
is selected, the swept signal generator steps to the
next point in the
stepped frequency sweep when an external hardware trigger is
received. When the last frequency point is reached and continuous
sweep is selected, the next trigger causes the step sweep to return to
the start frequency. Connect the trigger signal to the TRIGGER
INPUT BNC. An asterisk next to the key label indicates that this
feature is active.
Programming Codes
SCPI: SWEep:TRIGger:SOURce EXT
Analyzer:
TS
See Also
Step
Sup
Menu, Sweep Mode Step
“Using Step Sweep” in Chapter 1
(STOP)
Function Group
Menu Map
Description
Programming Codes
FREQUENCY
NONE
This
hardkey
activates swept frequency mode and makes the stop
frequency parameter the active function. The start/stop frequency
must be separated by at least 2 Hz in order to remain in the
frequency sweep mode. If start=stop frequency then the zero span
mode is entered.
SCPI:
FREQuency:STOP <num>[freq suffix] or
MAXimum]MINimum]UP]DOWN
FREQuency:MODE:SWEep
Analyzer:
FB <num> [Hz]Kz]Mz]Gz]
Operating and Programming Reference S-71
