tnstallation Procedure
1 Refer to Figure 3-3.
Remove handle trim strips.
2: Remove four screws per side.
3. Using the screws p
rovided,
attach the rack mount flanges to the
outside of the handles.
4 Remove the side straps and end caps.
5: Remove the bottom and back feet and the tilt stands.
Figure 3-3. Removing the Side Straps and Feet
Installation 3-11
