Master Master interconnect moduleinterconnect module with interconnect link module configurations with interconnect link module configurations
The following interconnect modules can be configured as the master switch, with interconnect link modules to support the master
interconnect module:
HPE Synergy Virtual Connect SE 40 Gb F8 Module
HPE Synergy 40Gb F8 Switch Module
HPE Virtual Connect SE 100Gb F32 Module for HPE Synergy
From one to four interconnect link modules are required to support the master interconnect module when using the following
interconnect link modules:
HPE Synergy 10Gb Interconnect Link Module
HPE Synergy 50Gb Interconnect Link Module in 25G mode
From one to two interconnect link modules are required to support the master interconnect module when using the following
interconnect link modules:
HPE Synergy 20Gb Interconnect Link Module
HPE Synergy 50Gb Interconnect Link Module in 50G mode
If redundancy is required, then two master switches are required per fabric. For the best availability with two or more frames, the two
switches or VC modules must be installed in different frames.
As an example of a redundant fabric 3 solution, one interconnect module or VC module would be installed in ICM bay 3 in one frame and
the second interconnect module or VC module would be installed in ICM bay 6 in another frame. ICM bays for the particular fabric that
do not contain the interconnect modules or VC modules would contain the interconnect link modules, providing redundancy for either an
interconnect module failure or frame failure.
The number of interconnect link cables is different depending on your Master/Satellite configuration:
MasterMaster SatelliteSatellite Number of interconnect link cablesNumber of interconnect link cables
HPE Virtual Connect SE 100Gb F32 Module
for HPE Synergy
HPE Synergy 50Gb Interconnect Link
Module
1 (for 25Gb speed)
2 (for 50Gb speed)
HPE Synergy 40Gb F8 Switch Module HPE Synergy 20Gb Interconnect Link
Module
2
HPE Synergy 40Gb F8 Switch Module HPE Synergy 10Gb Interconnect Link
Module
1
HPE Synergy Virtual Connect SE 40 Gb F8
Module
HPE Synergy 20Gb Interconnect Link
Module
2
HPE Synergy Virtual Connect SE 40 Gb F8
Module
HPE Synergy 10Gb Interconnect Link
Module
1
Master interconnect module with interconnect link module configurations 105

HP HPE Synergy 12000 Frame Specifications

General

Form Factor	Rack-mountable
Maximum Compute Modules	12
Management Module	HPE Synergy Composer
Cooling	Redundant fan modules
Power Supply	Redundant power supplies
Networking	HPE Synergy 12000 Frame Interconnect
Product Type	Blade Enclosure
Width	44.5 cm
Compliance	FCC, VCCI, BSMI, CCC, KCC, RoHS
Depth	36.25 in (92.08 cm)
