Cabling the Cabling the frameframe
WARNING:WARNING:
To reduce the risk of electric shock or injury due to high-current electrical energy, be sure that
all power is completely disconnected at the source before beginning any power connections to
the power bus bars or power bus box.
WARNING:WARNING:
Be sure that all circuit breakers are locked in the off position before connecting any power
components.
PrerequisitesPrerequisites
Download and review the HPE Synergy Cabling Guide from the Hewlett Packard Enterprise website (https://www.hpe.com/info/synergy-https://www.hpe.com/info/synergy-
docsdocs).
ProcedureProcedure
1. Cable the management network ports (MGMT and LINK).
2. Cable the HPE Synergy Image Streamer management ports.
3. Cable the interconnect modules.
4. Connect the power cables. Connect to the power source in your facility to each of the installed power supplies, and power up the
frame.
5. To configure HPE Synergy, connect to the HPE Synergy Console.
