NVDIMM-N LED combinationsNVDIMM-N LED combinations
StateState DefinitionDefinition NVDIMM-N Power LED (green)NVDIMM-N Power LED (green) NVDIMM-N Function LED (blue)NVDIMM-N Function LED (blue)
0 AC power is on (12V rail) but the NVM controller is
not working or not ready.
On Off
1 AC power is on (12V rail) and the NVM controller is
ready.
On On
2 AC power is off or the battery is off (12V rail off). Off Off
3 AC power is on (12V rail) or the battery is on (12V
rail) and the NVDIMM-N is active (backup and restore).
On Flashing
NVDIMM-N LED combinations 37

HP HPE Synergy 12000 Frame Specifications

General

Form Factor	Rack-mountable
Maximum Compute Modules	12
Management Module	HPE Synergy Composer
Cooling	Redundant fan modules
Power Supply	Redundant power supplies
Networking	HPE Synergy 12000 Frame Interconnect
Product Type	Blade Enclosure
Width	44.5 cm
Compliance	FCC, VCCI, BSMI, CCC, KCC, RoHS
Depth	36.25 in (92.08 cm)
