Installing the frame in a rackInstalling the frame in a rack
CAUTION: CAUTION: Always plan the rack installation so that the heaviest item is on the bottom of the rack. Install the heaviest
item first, and continue to populate the rack from the bottom to the top.
NOTE: NOTE: Up to four 10U frames can be installed in a 42U rack. If you are installing more than one frame, install the first
frame in the bottom of the rack, and then install additional frames by moving up the rack with each subsequent frame.
Plan rack installation carefully because it is difficult to change the location of components after they are installed.
ProcedureProcedure
1. Remove components from the frame.
2. Use the rack template to mark the locations for the rack rails.
3. Install the rack rails and cage nuts for each frame.
For more information, see the appropriate section according to the type of rack being used.
4. Install the frame into the rack .
5. Complete the component installation for your configuration.
Installing the frame in a rack 71

HP HPE Synergy 12000 Frame Specifications

General

Form Factor	Rack-mountable
Maximum Compute Modules	12
Management Module	HPE Synergy Composer
Cooling	Redundant fan modules
Power Supply	Redundant power supplies
Networking	HPE Synergy 12000 Frame Interconnect
Product Type	Blade Enclosure
Width	44.5 cm
Compliance	FCC, VCCI, BSMI, CCC, KCC, RoHS
Depth	36.25 in (92.08 cm)
