HPE Synergy 50Gb Interconnect Link Module interconnect link portsHPE Synergy 50Gb Interconnect Link Module interconnect link ports
Use an interconnect link cable when linking ports L1 or L2 to a master interconnect module.
NOTE:NOTE:
If you are running 25 Gb speeds, you only need one cable. If you are running 50 Gb speeds, you must connect two cables.
If you are connecting two cables, you must populate L1 first.
HPE Synergy 50Gb Interconnect Link Module interconnect link ports 54

HP HPE Synergy 12000 Frame Specifications

General

Form Factor	Rack-mountable
Maximum Compute Modules	12
Management Module	HPE Synergy Composer
Cooling	Redundant fan modules
Power Supply	Redundant power supplies
Networking	HPE Synergy 12000 Frame Interconnect
Product Type	Blade Enclosure
Width	44.5 cm
Compliance	FCC, VCCI, BSMI, CCC, KCC, RoHS
Depth	36.25 in (92.08 cm)
