NVDIMM Function LED patternsNVDIMM Function LED patterns
For the purpose of this table, the NVDIMM-N LED operates as follows:
Solid indicates that the LED remains in the on state.
Flashing indicates that the LED is on for 2 seconds and off for 1 second.
Fast-flashing indicates that the LED is on for 300 ms and off for 300 ms.
StateState DefinitionDefinition NVDIMM-N Function LEDNVDIMM-N Function LED
0 The restore operation is in progress. Flashing
1 The restore operation is successful. Solid or On
2 Erase is in progress. Flashing
3 The erase operation is successful. Solid or On
4 The NVDIMM-N is armed, and the NVDIMM-N is in normal operation. Solid or On
5 The save operation is in progress. Flashing
6 The NVDIMM-N finished saving and battery is still turned on (12 V still
powered).
Solid or On
7 The NVDIMM-N has an internal error or a firmware update is in
progress. For more information about an NVDIMM-N internal error, see
the IML.
Fast-flashing
NVDIMM Function LED patterns 38
