6 USB port Allows connection to the frame using a supported USB device. Devices include a
keyboard or mouse for connecting to the HPE Synergy Console. To connect multiple
devices, a USB hub (not included) is required.
Used for performing a USB recovery frame link module firmware update.
7 LINK port activity
LED
Reports LINK port activity:
Flashing green = Activity on the LINK port
Off = No activity on the LINK port
8 LINK port A 10GBASE-T RJ45 connector that provides two functions:
Provides high-availability management network connectivity between:
LINK ports on two frame link modules in the same frame for a single frame
configuration.
Frame link modules in different frames as part of a management network ring in
a multiframe configuration.
Provides management ring (frame link topology) connectivity for automatic frame
discovery by HPE OneView.
9 LINK port
connectivity LED
Reports LINK port connectivity:
Solid green = LINK port is connected.
Off = LINK port is not connected.
10 Monitor port Allows connection to the frame using a monitor device or an active monitor port
adapter.
ItemItem DescriptionDescription FunctionFunction
HPE Synergy Frame Link Module components and LEDs 46

HP HPE Synergy 12000 Frame Specifications

General

Form Factor	Rack-mountable
Maximum Compute Modules	12
Management Module	HPE Synergy Composer
Cooling	Redundant fan modules
Power Supply	Redundant power supplies
Networking	HPE Synergy 12000 Frame Interconnect
Product Type	Blade Enclosure
Width	44.5 cm
Compliance	FCC, VCCI, BSMI, CCC, KCC, RoHS
Depth	36.25 in (92.08 cm)
