3. Load paper in the tray. For information about how
to orient the paper, see Table 2-1 Tray 1 paper
orientation on page 19.
4. Adjust the width guides so that they touch the
paper stack, but do not bend it.
Tray 1 paper orientation
Table
2-1 Tray 1 paper orientation
Paper type Image orientation Duplex mode Paper size How to load paper
Letterhead or preprinted Portrait 1-sided printing 12x18, 11x17, RA3, A3, 8K
(273x394 mm), 8K
(270x390 mm), 8K
(260x368 mm), B4 (JIS),
Legal, Ocio (8.5x13), Ocio
(216x340 mm), C4, SRA4,
RA4, Arch A, A4, Letter, 16K
(197x273 mm) 16K
(195x270 mm), Executive,
A5, 16K (184x260 mm), B5
(JIS), Arch A, Statement, 5x8,
Double Japan Postcard
(148x200 mm), B6 (JIS), 5x7,
4x6, 10x15 cm, A6, Japanese
Postcard (100x148 mm)
Face-down
Bottom edge leading into the printer
ENWW Load paper to Tray 1 (multipurpose tray) 19
