HP PageWide Managed Color E77650

4
1
2
5
3
1 Host USB port for connecting external USB devices (this port might be covered)
NOTE: For easy-access USB printing, use the USB port near the control panel.
2 Local area network (LAN) Ethernet (RJ-45) network port
3 Hi-Speed USB 2.0 printing port
4 Fax port (fax models only)
5 Cable lock slot
Control-panel view
The Home screen provides access to the printer features and indicates the current status of the printer.
Return to the Home screen at any time by selecting the Home button.
NOTE: The features that appear on the Home screen can vary, depending on the printer conguration.
3 4
2
1
5 6 7
8
9
10
12
13
11
1
Home button
Select the Home button to return to the Home screen.
2 Applications area Select any of the icons to open the application. Swipe the screen sideways to access more applications.
NOTE: The available applications vary by printer. The administrator can congure which applications
appear and the order in which they appear.
ENWW Printer views 5
