117
staticroute 0/0 0/0
eviisis 0/0 0/0
ospf 0/0 1/0
Continue? [y/n]:y
Re-optimization of the placement start. You will be notified on completion
Re-optimization of the placement complete. Use 'display placement' to view the new
placement
# During the switchover period, display OSPF neighbors on Switch A to verify the neighbor
relationship between Switch A and Switch S.
<SwitchA> display ospf peer
OSPF Process 1 with Router ID 2.2.2.1
Neighbor Brief Information
Area: 0.0.0.0
Router ID Address Pri Dead-Time State Interface
3.3.3.1 12.12.12.2 1 37 Full/BDR Vlan100
# Display OSPF routes on Switch A to verify if Switch A has a route to the loopback interface on
Switch B.
<SwitchA> display ospf routing
OSPF Process 1 with Router ID 2.2.2.1
Routing Tables
Routing for Network
Destination Cost Type NextHop AdvRouter Area
44.44.44.44/32 2 Stub 12.12.12.2 4.4.4.1 0.0.0.0
14.14.14.0/24 2 Transit 12.12.12.2 4.4.4.1 0.0.0.0
22.22.22.22/32 0 Stub 22.22.22.22 2.2.2.1 0.0.0.0
12.12.12.0/24 1 Transit 12.12.12.1 2.2.2.1 0.0.0.0
Total Nets: 4
Intra Area: 4 Inter Area: 0 ASE: 0 NSSA: 0
# Display OSPF neighbors on Switch B to verify the neighbor relationship between Switch B and
Switch S.
<SwitchB> display ospf peer
OSPF Process 1 with Router ID 4.4.4.1
Neighbor Brief Information
Area: 0.0.0.0
Router ID Address Pri Dead-Time State Interface
3.3.3.1 14.14.14.2 1 39 Full/BDR Vlan200
# Display OSPF routes on Switch B to verify if Switch B has a route to the loopback interface on
Switch A.
<SwitchB> display ospf routing
OSPF Process 1 with Router ID 4.4.4.1
