[SwitchA-route-policy] apply fast-reroute backup-nexthop 30.1.1.3
[SwitchA-route-policy] quit
# Apply the routing policy to BGP FRR for BGP IPv4 unicast address family.
[SwitchA] bgp 100
[SwitchA-bgp] address-family ipv4 unicast
[SwitchA-bgp-ipv4] fast-reroute route-policy frr
[SwitchA-bgp-ipv4] quit
[SwitchA-bgp] quit
# On Switch D, configure the source address of BFD echo packets as 44.1.1.1.
[SwitchD] bfd echo-source-ip 44.1.1.1
# Create routing policy frr to set a backup next hop 3.3.3.3 (Switch C) for the route destined for
1.1.1.1/32.
[SwitchD] ip prefix-list abc index 10 permit 1.1.1.1 32
[SwitchD] route-policy frr permit node 10
[SwitchD-route-policy] if-match ip address prefix-list abc
[SwitchD-route-policy] apply fast-reroute backup-nexthop 3.3.3.3
[SwitchD-route-policy] quit
# Apply the routing policy to BGP FRR for BGP IPv4 unicast address family.
[SwitchD] bgp 200
[SwitchD-bgp] address-family ipv4 unicast
[SwitchD-bgp-ipv4] fast-reroute route-policy frr
[SwitchD-bgp-ipv4] quit
[SwitchD-bgp] quit
Verifying the configuration
# Display detailed information about the route to 4.4.4.4/32 on Switch A. The output shows the
backup next hop for the route.
[SwitchA] display ip routing-table 4.4.4.4 32 verbose
Summary Count : 1
Destination: 4.4.4.4/32
Protocol: BGP Process ID: 0
SubProtID: 0x2 Age: 00h01m52s
Cost: 0 Preference: 255
IpPre: N/A QosLocalID: N/A
Tag: 0 State: Active Adv
OrigTblID: 0x0 OrigVrf: default-vrf
TableID: 0x2 OrigAs: 200
NibID: 0x15000003 LastAs: 200
AttrID: 0x5 Neighbor: 10.1.1.2
Flags: 0x10060 OrigNextHop: 10.1.1.2
Label: NULL RealNextHop: 10.1.1.2
BkLabel: NULL BkNextHop: 30.1.1.3
Tunnel ID: Invalid Interface: Vlan-interface 100
BkTunnel ID: Invalid BkInterface: Vlan-interface 200
FtnIndex: 0x0
# Display detailed information about the route to 1.1.1.1/32 on Switch D. The output shows the
backup next hop for the route.
