[SwitchC-bgp-ipv6] quit
[SwitchC-bgp] quit
Verifying the configuration
# Execute the display bgp routing-table ipv6 command on Switch D.
[SwitchD] display bgp routing-table ipv6
Total number of routes: 5
BGP local router ID is 4.4.4.4
Status codes: * - valid, > - best, d - dampened, h - history,
s - suppressed, S - stale, i - internal, e - external
Origin: i - IGP, e - EGP, ? - incomplete
* >i Network : 1:: PrefixLen : 64
NextHop : 101::2 LocPrf : 100
PrefVal : 0 OutLabel : NULL
MED : 0
Path/Ogn: 100i
* >i Network : 100:: PrefixLen : 96
NextHop : 101::2 LocPrf : 100
PrefVal : 0 OutLabel : NULL
MED : 0
Path/Ogn: i
* >i Network : 101:: PrefixLen : 96
NextHop : 102::1 LocPrf : 100
PrefVal : 0 OutLabel : NULL
MED : 0
Path/Ogn: i
* > Network : 102:: PrefixLen : 96
NextHop : :: LocPrf :
PrefVal : 32768 OutLabel : NULL
MED : 0
Path/Ogn: i
* i Network : 102:: PrefixLen : 96
NextHop : 102::1 LocPrf : 100
PrefVal : 0 OutLabel : NULL
MED : 0
Path/Ogn: i
The output shows that Switch D has learned the network 1::/64 from Switch C through route
reflection.
