Configuring Access Control Lists 141
Figure 100. Add MAC ACL Page
3. Specify a sequence number to indicate the position of a rule within the ACL.
4. Specify the action for the rule:
Permit – The packet or frame is forwarded.
Deny – The packet or frame is dropped.
5. Specify the match criteria and rule attributes shown in Table 76.
6. Click Apply
Table 76. Extended MAC ACL Match Criteria
Field Description
Match Criteria
Every When this option is selected, all packets will match the rule and will be either permitted or
denied. This option is exclusive to all other match criteria, so if Every is selected, no other
match criteria can be configured. To configure specific match criteria, this option must be
clear.
CoS The 802.1p user priority value to match within the Ethernet frame.
EtherType The EtherType value to match in an Ethernet frame. Specify the number associated with the
EtherType or specify one of the following keywords: AppleTalk, ARP, IBM SNA, IPv4, IPv6,
IPX, MPLS, Unicast, NETBIOS, NOVELL, PPPoE, or RARP.
