Table 3-73 LED indicator description
Silk
Screen
Item Color Description
RUN Run
indicator
Green Steady on: Communication is normal
(including board startup, self-check, software
loading, and board power-on when not
loaded; excluding sleep when the power port
or PWR port is energized).
O: The ESM is in sleep mode.
Blinking at long intervals: The LUI is
querying data.
Blinking at short intervals: Communication is
interrupted.
ALM Fault
indicator
Red Steady on: There is a fault or major alarm.
O: There is no fault or major alarm.
Blinking slowly: Anti-theft lock.
CHG Charge
indicator
Green Steady on: The ESM is being charged.
O: The ESM is open-circuited or
discharging.
DCHG Discharge
indicator
Green Steady on: The ESM is discharging.
O: The ESM is open-circuited or being
charged.
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual 3 Components
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 95
