Figure 2-3 Internal structure (rear door)
(1) Rear door camera
(optional)
(2) ACDB220-40-1B (optional) (3) Space for the DC air
conditioner
(4) Electronic Lock (5) Light (6) ACDB220-63-12B
(optional)
(7) Door status sensor (8) ETP23006-C1A1 (optional) (9) Space for customer
equipment
(10) PDU2000-32-1PH-9
(optional)
(11) Lithium battery busbar (12) Space for lithium batteries
(13) Air purier (optional) (14) HAU03D-01 (optional)
NO TE
The gures showing the components installed on the front and rear doors of the cabinet
are for reference only. You can install the components based on site requirements.
