Powermax125 Service Manual 808070 109
Section 8
Troubleshooting and System Tests
Controls and indicators
The system’s controls and indicators are described in Basic System Operations on page 39. The following figures are
included for reference.
Rear panel
ON (I)/OFF (O) power switch Activates the power supply and its control circuits.
