Hypertherm Powermax 125 Service Manual

90 Powermax125 Service Manual 808070
6 – Machine Torch Setup
65 A shielded cutting – stainless steel
Air flow rate – slpm/scfh
Hot 222 / 470
Cold 250 / 530
Metric
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds mm/min volts mm/min volts
2
1.5
3.8 250
0.1 7405 119 9970 121
3 0.2 6120 120 8240 122
4
0.5
4840 122 6110 123
6 2275 125 2840 125
8
0.7
1505 127 1860 127
10
4.5 300
1115 130 1245 128
12 1.2 720 133 925 130
16
Edge Start
465 137 505 136
20 320 141 345 141
English
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm volts ipm volts
16 GA
0.06
0.15 250
0.1
316 118 425 120
10 GA 220 121 296 122
3/16 0.2 152 123 168 123
1/4 0.5 72 125 96 125
3/8 0.7 48 130 52 128
1/2 0.18 300 1.2 23 134 32 131
5/8
Edge Start
19 137 20 136
3/4 14 140 15 140

Hypertherm Powermax 125 Specifications

General

Output Current	30-125 A
Input Power	15.2 kW
Open Circuit Voltage	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Input Power Cable Length	10 ft (3 m)
Rated Output Current	125 A
Gas Type	Air or nitrogen
Cutting Capacity	1-1/4 inch (32 mm)
Pierce Capacity	1 inch (25 mm)
Input Voltage	200-600 V, 3-PH
Duty Cycle	100% @ 125 A
Certifications	CSA
Maximum Clean Cut Thickness	1-1/4 inch (32 mm)
Cooling Method	Fan-cooled
Torch Options	Hand
