Hypertherm Powermax 125 Service Manual

Powermax125 Service Manual 808070 95
6 – Machine Torch Setup
45 A shielded cutting – aluminum
Air flow rate – slpm/scfh
Hot 217 / 460
Cold 241 / 510
Metric
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds mm/min volts mm/min volts
1
1.5 3.8 250
0.0 9145 126 11100 124
2 0.1 7470 125 9210 124
3 0.2 4675 125 6190 125
4 0.4 3700 129 4845 127
6 0.5 1740 135 2795 132
English
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm volts ipm volts
1/32
0.06 0.15 250
0.0 360 126 450 124
1/16 0.1 360 126 400 124
3/32 0.2 233 124 328 124
1/8 0.4 177 126 224 125
1/4 0.5 55 136 96 133

Hypertherm Powermax 125 Specifications

General

Output Current	30-125 A
Input Power	15.2 kW
Open Circuit Voltage	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Input Power Cable Length	10 ft (3 m)
Rated Output Current	125 A
Gas Type	Air or nitrogen
Cutting Capacity	1-1/4 inch (32 mm)
Pierce Capacity	1 inch (25 mm)
Input Voltage	200-600 V, 3-PH
Duty Cycle	100% @ 125 A
Certifications	CSA
Maximum Clean Cut Thickness	1-1/4 inch (32 mm)
Cooling Method	Fan-cooled
Torch Options	Hand
