Hypertherm Powermax 125 Service Manual

Powermax125 Service Manual 808070 131
8 – Troubleshooting and System Tests
Perform a cold restart
Sometimes a “cold restart” clears the fault. When a cold restart is recommended in one of the Solutions below, do the
following:
1. Power OFF the machine.
2. Wait 30 seconds or until the red LED near the top of the DSP board blinks once.
3. Power ON the machine.
Fault codes and solutions
Each table below describes a fault category and suggests solutions for each fault code. Several of the fault solutions
show a test number. Refer to System tests on page 149 to perform the indicated numbered test.

If a fault occurs while using a generator, turning the power switch quickly to OFF and then
to ON again (sometimes called a “quick reset”) may not clear the fault. Instead, see
Perform a cold restart on page 131.
Fault code format – 0-00-0
This fault code indicates normal operations.
0-00-0
Fault
code
Description
Power
LED
Fault
LED
Fault
icon
Solutions
0-00-0 None On Off - No errors

Hypertherm Powermax 125 Specifications

General

Output Current	30-125 A
Input Power	15.2 kW
Open Circuit Voltage	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Input Power Cable Length	10 ft (3 m)
Rated Output Current	125 A
Gas Type	Air or nitrogen
Cutting Capacity	1-1/4 inch (32 mm)
Pierce Capacity	1 inch (25 mm)
Input Voltage	200-600 V, 3-PH
Duty Cycle	100% @ 125 A
Certifications	CSA
Maximum Clean Cut Thickness	1-1/4 inch (32 mm)
Cooling Method	Fan-cooled
Torch Options	Hand
