Powermax125 Service Manual 808070 25
1 – Specifications
Powermax125 cutting specifications
Handheld cut capacity (material thickness)
Recommended cut capacity at 457 mm/min (18 ipm)
1
38 mm (1-1/2 inches)
Recommended cut capacity at 250 mm/min (10 ipm)
1
44 mm (1-3/4 inches)
Severance capacity at 125 mm/min (5 ipm)
1
57 mm (2-1/4 inches)
Pierce capacity (material thickness)
Pierce capacity for handheld cutting, or mechanized cutting with
programmable torch height control
25 mm (1 inch)
Pierce capacity for mechanized cutting without programmable torch height
control
22 mm (7/8 inch)
Maximum cut speed
2
(mild steel)
6mm (1/4inch) 7160 mm/min (282 ipm)
10 mm (3/8 inch) 4390 mm/min (173 ipm)
12 mm (1/2 inch) 2950 mm/min (116 ipm)
16 mm (5/8 inch) 2110 mm/min (83 ipm)
20 mm (3/4 inch) 1470 mm/min (58 ipm)
22 mm (7/8 inch) 1170 mm/min (46 ipm)
25 mm (1 inch) 940 mm/min (37 ipm)
32 mm (1-1/4 inches) 610 mm/min (24 ipm)
38 mm (1-1/2 inches) 457 mm/min (18 ipm)
Gouging capacity
Metal removal rate on mild steel (125 A) 12.5 kg/hour (27 pounds/hour)
Duramax Hyamp series torch weights (refer to Component weights (125 A systems) on page 21)
Duty cycle and voltage information (refer to Hypertherm power supply ratings on page 22)
1
Cut capacity speeds are not necessarily maximum speeds. They are the speeds that must be achieved to be rated at that
thickness.
2
Maximum cut speeds are the results of Hypertherm’s laboratory testing. Actual cutting speeds may vary based on different cutting
applications.
