220 Powermax125 Service Manual 808070
9 Power Supply Component Replacement
Figure 80
J1 J2 J3 J5 J6
J1 J2 J3 J5 J6
1
2
3
4
5
6
1 Pressure transducer
2 Push-to-connect plastic ring
3 Solenoid valve
4 Transducer wires
5 Left grommet
6 Power board connectors
