Display Messages
168
P69 ERROR:
EC STOPPED AT STATE XXXX
(continued)
11. Power on the printer in download mode and load flash memory
(page 238).
12. If you encounter the failure after replacing the controller board,
reinstall the original controller board and contact your DDS and
Second Level Support.
PLEASE WAIT...
RESET IN PROGRESS
Status message: the printer
finished loading the program into
flash memory and is automatically
resetting itself.
No action required.
RESETTING...PLEASE WAIT
Status message: the printer is
resetting itself.
No action required.
RESTORING BOOT CODE
Status message when
downloading boot code. Code is
checked then saved in flash
memory.
No action required.
SERVICE
<service test>
Non-error status message. No action required.
SHUTTLE TYPE
NOT SUPPORTED*
The shuttle type was not detected
at power-up.
1. Power off and unplug the printer. Remove the paper guide
assembly or top cover to gain access to the card cage. Make sure
the shuttle data and power cables are undamaged and have good
connections at the shuttle and the controller board.
2. Plug in the printer and power it on. If the message appears,
replace the controller board. Record the message and return it
with the defective board.
3. Power on the printer. If the message appears, replace the shuttle
frame assembly.
SPX FOUND, ERROR:
KEY NOT DETECTED
The controller board does not
have a security key.
1. Remove the SPX from the RJ-12 Debug Port.
2. Power down the printer.
3. Install the security key.
Table 3. Message List
Operator Panel Message Explanation Corrective Action
To Next Page
