287
Cable Assembly, Twinax Auto-Termination
White
Gray
Shield
14
7
5
Jack
Jack
12
34
Resistance Chart
Pin Pin Ohms
1
3
1, 2, 3, 4
5
14
7
2
4
Shield
Shield
1, 4
2, 3
110
110
55
0
0
0
38F8254
NOTE: If the printer has a PSA3 controller
and power stacker, Smart-T Cable Extension
75P2813 is also required (see the next
page).
