How To Identify The Printer
30
How To Identify The Printer
The model number of the printer indicates the printer family, rated maximum print speed, and type of enclosure. (See Figure 3.)
Figure 3. This figure shows how to interpret printer model numbers.
Table 1. The Infoprint 6500 Printer Family
Model Number
Print Speed of
Draft Mode Text
Enclosure Hammer Bank
6500-v05 500 LPM * Floor Cabinet 28 Hammers
6500-v5P 500 LPM Pedestal 28 Hammers
6500-v10 1000 LPM Floor Cabinet 60 Hammers
6500-v1P 1000 LPM Pedestal 60 Hammers
6500-v15 1500 LPM Floor Cabinet 102 Hammers
6500-v20 2000 LPM Floor Cabinet 126 Hammers
* Lines Per Minute
Infoprint 6500 Printer Family
6500-v5P
Housing Code:
P = Pedestal Model
0 or 5 = Cabinet Model
Speed Rating:
v05 = 500 LPM
v5P = 500 LPM
v10 = 1000 LPM
v1P = 1000 LPM
v15 = 1500 LPM
v20 = 2000 LPM
