296
Cable Assembly, Hammer Bank Power
Wire Table
P05 P105
21
12
43
34
65
56
87
78
10 9
910
39U2533
To Shuttle
To Controller Board
IMPORTANT:
Use this cable on all Infoprint 6500
printers except
the 6500-v20. On the
6500-v20 use 54P1455, shown on
the next page.
