Operator Panel Assembly
347
Operator Panel Assembly
NOTE: The procedure for removing and installing the operator panel is the same for cabinet and pedestal model printers.
Removal
1. Prepare the printer for maintenance (page 313).
2. Open the printer cover.
3. Disconnect the RJ-11 connector P310 from J2 on the back of the operator panel. (See Figure 37, page 396.)
4. Remove the two screws securing the operator panel to the panel bracket.
5. Remove the operator panel assembly from the panel bracket.
Installation
1. Engage the slot on the bottom of the operator panel on the bottom edge of the panel bracket cutout. (See Figure 37, page
396.)
2. Align the holes on the top rear of the operator panel with the holes in the upper edge of the panel bracket, and install the
two mounting screws.
3. Connect RJ-11 connector P310 to connector J2 on the rear of the operator panel.
4. Return the printer to normal operation (page 314).
