Chapter 5 Removal And Replacement Procedures
322
Circuit Breaker
Removal
1. Prepare the printer for maintenance (page 313).
2. Open the printer cover.
3. Remove the card cage fan (page 331).
4. Disconnect the four circuit breaker electrical leads.
(Cabinet Model: See Figure 47, page 419.
Pedestal Model: See Figure 41, page 404.)
5. Press in on the spring clips and remove the circuit breaker from the printer.
Installation
6. Press the circuit breaker into the cutout until the spring clips snap into place.
(Cabinet Model: See Figure 47, page 419.
Pedestal Model: See Figure 41, page 404.)
ATTENTION Make sure the four leads are connected as shown on page 419 and page 404.
7. Connect the four circuit breaker electrical leads.
(Cabinet Model: See Figure 47, page 419.
Pedestal Model: See Figure 41, page 404.)
8. Install the card cage fan (page 331).
9. Return the printer to normal operation (page 314).
