3 Locations
Locations Of Components And Assemblies
Belt, Paper Feed Timing ................................................................................................................. page 400, Figure 39, item 7
Belt, Platen Open .......................................................................................................................... page 413, Figure 45, item 24
Circuit Board: PSA3 Controller........................................................................................................ page 406, Figure 42, item 6
Circuit Board: Power Supply ......................................................................................................... page 406, Figure 42, item 15
Circuit Breaker ............................................................................. page 419, Figure 47, item 1 and page 404, Figure 41, item 6
Connector Shells ........................................................................................................................................ page 324, Figure 14
Cover Assembly, Hammer Bank / Ribbon Mask ..........................................................................................page 325, Figure 15
Cover Assembly, Shuttle................................................................................................................. page 400, Figure 39, item 2
Cover Assembly, Top, Pedestal Model ........................................................................................... page 398, Figure 38, item 9
Dashpot........................................................................................................................................... page 396, Figure 37, item 5
Doors, Cabinet ................................................................................................................................ page 392, Figure 35, item 5
Ethernet Interface Assembly ............................................................................................................ page 423, Figure 49, item 1
Fan Assembly, Cabinet Exhaust..................................................................................................... page 396, Figure 37, item 8
Fan Assembly, Card Cage .......................................................... page 416, Figure 46, item 1 and page 404, Figure 41, item 2
Fan Assembly, Hammer Bank ...................................................................................................... page 416, Figure 46, item 22
Hammer Spring Assembly .......................................................................................................................... page 334, Figure 16
IBM Coax/Twinax Expansion Board................................................................................................ page 421, Figure 48, item 1
Magnetic Pick-up (MPU) Assembly................................................................................................. page 409, Figure 43, item 1
Memory Modules and Security Key ............................................................................................................ page 341, Figure 18
Motor Assembly, Paper Feed.......................................................................................................... page 416, Figure 46, item 5
